2024 INSPYRE Evo Disc Complete Bike

 The Evo Disk has been designed to bring maximum benefits to the rider for advancing and improving in competition. This bike is intended for intermediate riders seeking more dynamism and performance.

The complete Evo bike range comes in 7 sizes ranging from Junior to Cruiser. For each bike size, the components are selected to best suit the user's morphology and provide maximum support on the track.

The bike is built around the Inspyre Bicycles® Evo Disk frame, incorporating all the features of a high-end BMX Race frame. Hydroformed tubes made of 6061-T6 aluminum ensure an excellent weight-to-performance ratio. Its geometry allows it to be both stable and responsive. The frame includes the Inspyre Bicycles® Swell rear dropouts. In addition to adding rigidity to the rear of the frame, these dropouts allow for the integration of the Pride Racing® disc brake mount while offering perfect chain tension.

The Evo Disk is composed of high-end "aftermarket" parts. It features the Forward® Joyride 6061-T6 aluminum crankset, the excellent Forward® Joyride V2 hubs with 100% sealed bearings. The rear hub incorporates a 6-pawl system with 150 engagement points that rivals high-end hubs on the market.

In this 2024 version, the Evo is equipped with high-performance Tioga Powerblock tires. These tires provide efficiency and dynamism. The tire width is adaptable according to bike sizes.

The Evo Disk is a bike ready to tackle races, but above all, ready to win.

KEY FEATURES:

• INSPYRE BICYCLES® Aluminum 6061-T6 Frame
• SHIMANO® MT401/410 disc brake kit
• TIOGA® Powerblock tires
• PRIDE RACING® integrated or semi-integrated headset (ZS or IS, depending on bike sizes)
• Swell rear dropouts with integrated chain tensioners
• 100% sealed bearings
• FORWARD® BSA bottom bracket
• FORWARD® Joyride V2 rear hub - 150 points of engagement - 6-pawl system - 100% sealed bearings
• KMC® Z-1 Chain

Spec: Junior 18.75"TT

FRAME Inspyre Evo Disk Junior - 18.75’’ Premium Alu 6061-T6 - Hydroformed tubes - Triple butted - Swell Forged 3D Dropouts
FORK Inspyre Evo - 100% Chromoly - 1-1/8’' Steerer Tube - Tapered Legs
HEADSET Semi Integrated - Sealed bearings - ZS44 | ZS44
HANDLEBAR Inspyre Evo - Aluminium - 22.2mm - 4.25’’ x 22’’ - BS: 7° / US: 2°
GRIPS Forward Lock On 95mm - Kraton
STEM Forward - Top Load - Aluminium 6061-T6 - 40mm
BRAKE LEVER Shimano BL-MT401 - Right lever - Black
BRAKE CALIPER Shimano BR-MT410 - Rear caliper - Post Mount - Resin pads
DISC Forward 140mm disc
BOTTOM BRACKET FORWARD® external BSA - Sealed bearings
CRANKSET Forward Joyride AM 2-piece - 4-bolt (104 BCD) - 150mm
PEDALS Aluminum Mini 9/16
SPROCKET 4-bolt Aluminum 38T
CHAIN KMC® Z-1 - 1/2’’ x 3/32’’
COG 16T - 1/2’’ x 3/32’’ - Chromoly
FRONT RIM Forward Joyride - Aluminum 28H - Double-wall
REAR RIM Forward Joyride - Aluminum 28H - Double-wall
FRONT TIRE Tioga Fastr X - 20x1-3/8’’ - Rigid beads - 60 TPI
REAR TIRE Tioga Powerblock - 20x1-1/8’’ - Rigid beads - 60 TPI
FRONT HUB Forward Joyride - Aluminum 28H - 10mm - 100% Sealed bearings - Female bolts
REAR HUB Forward Joyride Disc - Aluminum Cassette 28H - 10mm - 100% Sealed bearings - 150 engagement points - 6-pawl system - Female bolts
SPOKES Stainless 14G
NIPPLES Brass 14G
SEAT Combo Saddle Nylon Seatpost - Seat: 168x108mm - Seatpost: 162x22.2mm
SEAT CLAMP Forward AM 25.4mm
TENSIONERS Integrated Swell Dropouts
WEIGHT 7,85kg without pedals

Specs: Expert 19.5"TT

FRAME Inspyre Evo Disk Junior - 19.5’’ Premium Alu 6061-T6 - Hydroformed tubes - Triple butted - Swell Forged 3D Dropouts
FORK Inspyre Evo - 100% Chromoly - 1-1/8’' Steerer Tube - Tapered Legs
HEADSET Semi Integrated - Sealed bearings - ZS44 | ZS44
HANDLEBAR Inspyre Evo - Aluminium - 22.2mm - 5.5’’ x 22'’ - BS: 7° / US: 2°
GRIPS Forward Lock On 130mm - Kraton
STEM Forward - Top Load - Aluminum 6061-T6 - 40mm
BRAKE LEVER Shimano BL-MT401 - Right lever - Black
BRAKE CALIPER Shimano BR-MT410 - Rear caliper - Post Mount - Resin pads
DISC Forward 140mm disc
BOTTOM BRACKET FORWARD® external BSA - Sealed bearings
CRANKSET Forward Joyride AM 2-piece - 4-bolt (104 BCD) - 160mm
PEDALS Aluminum 9/16
SPROCKET 4-bolt Aluminum 40T
CHAIN KMC® Z-1 - 1/2’’ x 3/32’’
COG 16T - 1/2’’ x 3/32’’ - Chromoly
FRONT RIM Forward Joyride - Aluminum 28H - Double-wall
REAR RIM Forward Joyride - Aluminum 28H - Double-wall
FRONT TIRE Tioga Powerblock - 20x1-3/8’’ - Wire beads - 60 TPI
REAR TIRE Tioga Powerblock - 20x1-1/8’’ - Wire beads - 60 TPI
FRONT HUB Forward Joyride - Aluminum 28H - 10mm - 100% Sealed bearings - Female bolts
REAR HUB Forward Joyride Disc - Aluminum Cassette 28H - 10mm - 100% Sealed bearings - 150 engagement points - 6-pawl system - Female bolts
SPOKES Stainless 14G
NIPPLES Brass 14G
SEAT Combo Saddle Nylon Seatpost - Seat: 214x113mm - Seatpost: 162x27.2mm
SEAT CLAMP Forward AM 31.8mm
TENSIONERS Integrated Swell Dropouts
WEIGHT 8kg without pedals

Specs: Expert XL - 20.00" TT

FRAME Inspyre Evo Disk Expert XL - 20’’ - Premium Alu 6061-T6 - Hydroformed tubes - Triple butted - Swell Forged 3D Dropouts
FORK Inspyre Evo - 100% Chromoly - 1-1/8’' Steerer Tube - Tapered Legs
HEADSET Pride Racing - Tapered Integrated - Sealed bearings - IS42 | IS52
HANDLEBAR Inspyre Evo - 100% Crmo - 22.2mm - 6’.5’ x 26’’ - BS: 7° / US: 2°
GRIPS Forward Lock On 130mm - Kraton
STEM Forward - Top Load - Aluminum 6061-T6 - 50mm
BRAKE LEVER Shimano BL-MT401 - Right lever - Black
BRAKE CALIPER Shimano BR-MT410 - Rear caliper - Post Mount - Resin pads
DISC Forward 140mm disc
BOTTOM BRACKET FORWARD® external BSA - Sealed bearings
CRANKSET Forward Joyride AM 2-piece - 4-bolt (104 BCD) - 170mm
PEDALS Aluminum 9/16
SPROCKET 4-bolt Aluminum 41T
CHAIN KMC® Z-1 - 1/2’’ x 3/32’’
COG 16T - 1/2’’ x 3/32’’ - Chromoly
FRONT RIM Forward Joyride - Aluminum 36H - Double-wall
REAR RIM Forward Joyride - Aluminum 36H - Double-wall
FRONT TIRE Tioga Powerblock - 20x1.40’’ - Rigid beads - 60 TPI
REAR TIRE Tioga Powerblock - 20x1.40’’ - Rigid beads - 60 TPI
FRONT HUB Forward Joyride - Aluminum 36H - 10mm - 100% Sealed bearings - Female bolts
REAR HUB Forward Joyride Disc - Aluminum Cassette 36H - 10mm - 100% Sealed bearings - 150 engagement points - 6-pawl system - Female bolts
SPOKES Stainless 14G
NIPPLES Brass 14G
SEAT Combo Saddle Nylon Seatpost - Seat: 214x113mm - Seatpost: 162x27.2mm
SEAT CLAMP Forward AM 31.8mm
TENSIONERS Integrated Swell Dropouts
WEIGHT 8,88kg

Specs: Pro - 20.75"TT

FRAME Inspyre Evo Disk Pro - 20.75’’ - Premium Alu 6061-T6 - Hydroformed tubes - Triple butted - Swell Forged 3D Dropouts
FORK Inspyre Evo - 100% Chromoly - 1-1/8 - Tapered Steerer Tube - Tapered Legs
HEADSET Pride Racing - Tapered Integrated - Sealed bearings - IS42 | IS52
HANDLEBAR Inspyre Evo - 100% Crmo - 22.2mm - 7.5’’ x 26.7’’ - BS: 7° / US: 1.5°
GRIPS Forward Lock On 130mm - Kraton
STEM Forward - Top Load - Aluminum 6061-T6 - 50mm
BRAKE LEVER Shimano BL-MT401 - Right lever - Black
BRAKE CALIPER Shimano BR-MT410 - Rear caliper - Post Mount - Resin pads
DISC Forward 140mm disc
BOTTOM BRACKET FORWARD® external BSA - Sealed bearings
CRANKSET Forward Joyride AM 2-piece - 4-bolt (104 BCD) - 175mm
PEDALS Aluminum 9/16
SPROCKET 4-bolt Aluminum 42T
CHAIN KMC® Z-1 - 1/2’’ x 3/32’’
COG 16T - 1/2’’ x 3/32’’ - Chromoly
FRONT RIM Forward Joyride - Aluminum 36H - Double-wall
REAR RIM Forward Joyride - Aluminum 36H - Double-wall
FRONT TIRE Tioga Fastr X - 20x1.75’’ - Rigid beads - 60 TPI
REAR TIRE Tioga Powerblock - 20x1.60’’ - Rigid beads - 60 TPI
FRONT HUB Forward Joyride - Aluminum 36H - 10mm - 100% Sealed bearings - Female bolts
REAR HUB Forward Joyride Disc - Aluminum Cassette 36H - 10mm - 100% Sealed bearings - 150 engagement points - 6-pawl system - Female bolts
SPOKES Stainless 14G
NIPPLES Brass 14G
SEAT Combo Saddle Nylon Seatpost - Seat: 214x113mm - Seatpost: 162x27.2mm
SEAT CLAMP Forward AM 31.8mm
TENSIONERS Integrated Swell Dropouts
WEIGHT 9,13kg

Specs: Pro XL - 21.25"TT

FRAME Inspyre Evo-C Disk Pro XL - 21.25’’- Premium Alu 6061-T6 - Hydroformed tubes - Triple butted - Swell forged 3D dropouts
FORK Inspyre Evo - 100% Chromoly - 1-1/8" Pivot - Tapered legs
HEADSET Pride Racing - Tapered Integrated - Sealed bearings - IS42 | IS52
HANDLEBAR Inspyre Evo - 100% Crmo - 22.2mm - 8’’ x 28.5’’ - BS: 7° / US: 1.5°
GRIPS Forward Lock On 130mm - Kraton
STEM Forward - Top Load - Aluminum 6061-T6 - 50mm
BRAKE LEVER Shimano BL-MT401 - Right lever - Black
BRAKE CALIPER Shimano BR-MT410 - Rear caliper - Post Mount - Resin pads
DISC Forward 140mm disc
BOTTOM BRACKET FORWARD® external BSA - Sealed bearings
CRANKSET Forward Joyride AM 2-piece - 4-bolt (104 BCD) - 175mm
PEDALS Aluminum 9/16
SPROCKET 4-bolt Aluminum 43T
CHAIN KMC® Z-1 - 1/2’’ x 3/32’’
COG 16T - 1/2’’ x 3/32’’ - Chromoly
FRONT RIM Forward Joyride - Aluminum 36H - Double-wall
REAR RIM Forward Joyride - Aluminum 36H - Double-wall
FRONT TIRE Tioga Powerblock - 20x1.75’’ - Rigid beads - 60 TPI
REAR TIRE Tioga Powerblock - 20x1.75’’ - Rigid beads - 60 TPI
FRONT HUB Forward Joyride - Aluminum 36H - 10mm - 100% Sealed bearings - Female bolts
REAR HUB Forward Joyride Disc - Aluminum Cassette 36H - 10mm - 100% Sealed bearings - 150 engagement points - 6-pawl system - Female bolts
SPOKES Stainless 14G
NIPPLES Brass 14G
SEAT Combo Saddle Nylon Seatpost - Seat: 214x113mm - Seatpost: 162x27.2mm
SEAT CLAMP Forward AM 31.8mm
TENSIONERS Integrated Swell Dropouts
WEIGHT 9,83kg

Specs: Pro XXL - 21.85"TT

FRAME Inspyre Evo-C Disk Pro XXL - 21.85’’- Premium Alu 6061-T6 - Hydroformed tubes - Triple butted - Swell forged 3D dropouts
FORK Inspyre Evo - 100% Chromoly - 1-1/8" Pivot - Tapered legs
HEADSET Pride Racing - Tapered Integrated - Sealed bearings - IS42 | IS52
HANDLEBAR Inspyre Evo - 100% Crmo - 22.2mm - 8’’ x 28.5’’ - BS/ 7° / US/ 1.5°
GRIPS Forward Lock On 130mm - Kraton
STEM Forward - Top Load - Aluminum 6061-T6 - 50mm
BRAKE LEVER Shimano BL-MT401 - Right lever - Black
BRAKE CALIPER Shimano BR-MT410 - Rear caliper - Post Mount - Resin pads
DISC Forward 140mm disc
BOTTOM BRACKET FORWARD® external BSA - Sealed bearings
CRANKSET Forward Joyride AM 2-piece - 4-bolt (104 BCD) - 180mm
PEDALS Aluminum 9/16
SPROCKET 4-bolt Aluminum 44T
CHAIN KMC® Z-1 - 1/2’’ x 3/32’’
COG 16T - 1/2’’ x 3/32’’ - Chromoly
FRONT RIM Forward Joyride - Aluminum 36H - Double-wall
REAR RIM Forward Joyride - Aluminum 36H - Double-wall
FRONT TIRE Tioga Powerblock - 20x1.75’’ - Rigid beads - 60 TPI
REAR TIRE Tioga Powerblock - 20x1.75’’ - Rigid beads - 60 TPI
FRONT HUB Forward Joyride - Aluminum 36H - 10mm - 100% Sealed bearings - Female bolts
REAR HUB Forward Joyride Disc - Aluminum Cassette 36H - 10mm - 100% Sealed bearings - 150 engagement points - 6-pawl system - Female bolts
SPOKES Stainless 14G
NIPPLES Brass 14G
SEAT Combo Saddle Nylon Seatpost - Seat/ 214x113mm - Seatpost/ 162x27.2mm
SEAT CLAMP Forward AM 31.8mm
TENSIONERS Integrated Swell Dropoutsers
WEIGHT 9,87kg

Specs: Pro Cruiser - 21.85"TT

FRAME Inspyre Evo Disk Cruiser - 21.85’’ - Premium Aluminum 6061-T6 - Hydroformed tubes - Triple butted - Swell forged 3D dropouts
FORK Inspyre Evo 24" - 100% Chromoly - 1-1/8" Pivot - Tapered legs
HEADSET Pride Racing - Tapered Integrated - Sealed bearings - IS42 | IS52
HANDLEBAR Inspyre Evo - 100% CrMo - 5.5’’ x 27.5’’ - BS: 7° / US: 1.5° - 22.2mm
GRIPS Forward Lock On 130mm - Kraton
STEM Forward - Top Load - Aluminum 6061-T6 - 50mm
BRAKE LEVER Shimano BL-MT401 - Right lever - Black
BRAKE CALIPER Shimano BR-MT410 - Rear caliper - Post Mount - Resin pads
DISC Forward 140mm disc
BOTTOM BRACKET Forward external BSA - Sealed bearings
CRANKSET Forward Joyride AM 2-piece - 4-bolt (104 BCD) - 175mm
PEDALS Aluminum 9/16
SPROCKET Aluminum 4-bolt 41T
CHAIN KMC® Z-1 - 1/2’’ x 3/32’’
COG 18T - 1/2’’ x 3/32’’ - Chromoly
FRONT RIM Forward Joyride 24" - Aluminum 36H - Double-wall
REAR RIM Forward Joyride 24" - Aluminum 36H - Double-wall
FRONT TIRE Tioga Powerblock - 24x1.75’’ - Wire bead - 60 TPI
REAR TIRE Tioga Powerblock - 24x1.60’’ - Wire bead - 60 TPI
FRONT HUB Forward Joyride V2 - Aluminum body - 36H - 10mm - 100% Sealed bearings - Female bolts
REAR HUB Forward Joyride V2 Disc - Aluminum cassette body - 36H - ISO 6 - 100% Sealed bearings - 150 points of engagement - 6-pawl system - Female bolts 10mm
SPOKES Stainless 14G
NIPPLES Brass 14G
SEAT Combo Saddle Nylon Seatpost - Seat: 214x113mm - Seatpost: 162x27.2mm
SEAT CLAMP Forward AM - 31.8mm
TENSIONERS Integrated Swell Dropouts
WEIGHT 10,11kg
