PROFILE 'MULVILLE' PUSH STEM 63MM REACH

PROFILE MULVILLE PUSH TOP-LOAD BMX STEM

Profile Racing have been pumping out the popular top-load "Mulville" Push stems since 2009. The undisputed best selling BMX top-load stem of all time is available in 4 different reaches; 48, 53, 58 and 63mm and 10 colours (with plenty of limited edition finishes released over the years). The stem's unique design provides a 31.7mm rise, which is taller than your average top-load stem. If you are looking to save additional weight you can upgrade to titanium bolts.

• The “Push” stem is named after Mark’s favorite trails.
• Locates bars 23mm (.9 inches) higher than the Acoustic Stem.

Steerer Tube Size: 1-1/8″(28.58mm)

Handelbar Size: 7/8″(22.22mm)

Sizes: 48mm, 53mm, 58mm, 63mm

Colors: Black, Polished, Red, Blue, Green, Purple, White, Matte Black,  Gold, Aqua

Reach: 48mm
Stack Height: 33mm
Rise: 31.7mm (Upright) / 1.3mm (Invert)
Clamp bolts: 5/16″x18tpi (x4)
Pinch Bolts: 5/16″x18tpi (x2)
Weight: with chromo bolts: 283g/9.95oz with titanium bolts: 253g/8.95oz

Reach: 53mm
Stack Height: 33mm
Rise: 31.7mm (Upright) / 1.3mm (Invert)
Clamp bolts: 5/16″x18tpi (x4)
Pinch Bolts: 5/16″x18tpi (x2)
Weight: with chromo bolts: 297g/10.45oz with titanium bolts: 267g/9.45oz

Reach: 58mm
Stack Height: 33mm
Rise: 31.7mm (Upright) / 1.3mm (Invert)
Clamp bolts: 5/16″x18tpi (x4)
Pinch Bolts: 5/16″x18tpi (x2)

Because 58mm Push stems are older stock, most of them have not been updated with a recessed steer tube hole.
Weight: with chromo bolts: 310g/10.85oz with titanium bolts: 280/9.85oz

Reach: 63mm
Stack Height: 33mm
Rise: 31.7mm (Upright) / 1.3mm (Invert)
Clamp bolts: 5/16″x18tpi (x4)
Pinch Bolts: 5/16″x18tpi (x2)
